Brush Brushless Electric Micro DC Motor PMDC M20 DC 3V 13800 Rpm Customized

Place of Origin China
Brand Name TCS
Certification ISO9001、ISO14001、IATF16949、ROHS、REACH
Model Number JFB1015
Minimum Order Quantity 10000PCS
Price USD0.60 1000PCS
Packaging Details Carton with foam pad
Delivery Time 25 working days
Payment Terms T/T
Supply Ability 100000+pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Voltage DC 3V Warranty 3months-1year
Speed(RPM) 11040 Rpm Construction Permanent Magnet
Commutation Brush Continuous Current(A) 0.045 A
Outline Dimension 15.4 Mm Lifetime More Than 500H(continuous Operation)
High Light

PMDC Micro DC Motor

,

13800 Rpm Micro DC Motor

,

DC 3V Brushed DC Electric Motor

Leave a Message
Product Description

M20 DC 3V 13800 Rpm Bearing PMDC Electric Brush Brushless DC Motor Customized



Quick Detail:

  • The voltage is 3V(can be customized in 1V to 3V)
  • The construction is permanent magnet
  • The communication is brush
  • REACH,ROHS,ISO9001,ISO14001
  • 1 year warranty

 Description:



What is a micro motor?

Micro motor is a small size, light weight, and low-power motor that can meet various usage requirements; Full name for micro special motor, abbreviated as micro motor

Micro motors, also known as motors, are represented by the letter "M" in circuits. Its main function is to generate driving torque as a power source for electrical appliances or small machinery (such as air pumps, gearboxes, etc.)



Specifications:

item
value
Warranty
3months-1year
Place of Origin
China

Guangdong
Brand Name
TCS Precision
Model Number
JFB1015
Usage
Car, Electric Bicycle, FAN, Home Appliance, SMART HOME
Type
Micro Motor
Torque
11 g.cm at stall
Construction
Permanent Magnet
Commutation
Brush
Protect Feature
Totally Enclosed
Speed(RPM)
11040 rpm
Continuous Current(A)
0.045 A
Efficiency
IE 1
Model
JFB1015
Voltage
3 v (can be customized in 1 V to 3 V)
current
0.045 A
Outline Dimension
15.4 mm
Lifetime
More than 500H(continuous operation)
Rotation
CCW/CW reversible
Product Name
Brush Dc Electric Motor
Customized accept
Yes



Model: JFB1015
Voltage
No-load
Maximum Efficiency Point
Stall
Range volt.
Rated volt.
Speed
(RPM)
Current (A)
Speed(RPM)
Current (A)
Torgue
(g.cm)
Power
(W)
Torgue
(g.cm)
Current
(A)
1.5~3V
2V
8500
0.034
6630
0.126
1.87
0.12
8.5
0.455



2~4V
3V
13800
0.045
11040
0.169
2.2
0.249
11
0.665

Brush Brushless Electric Micro DC Motor PMDC M20 DC 3V 13800 Rpm Customized 0

Brush Brushless Electric Micro DC Motor PMDC M20 DC 3V 13800 Rpm Customized 1


Applications:





Brush Brushless Electric Micro DC Motor PMDC M20 DC 3V 13800 Rpm Customized 2









FAQ:



Q1. Can I have a sample order for micro motors?

A: Yes, we welcome sample order to test and check quality.



Q2. What about the lead time?

A: 3-5 days for Sample preparing ,20-25working days for mass production.



Q3. Do you have any MOQ limit for micro motors order?

A: Yes,1000pcs MOQ, 1-10pcs for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.



Q5. How to proceed an order for micro motors?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.



Q6. What are the terms of trade?

A: FOB, EXW



Q7: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products.



Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.



Secondly, during the guarantee period, we will send new air pump with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
